Xena-M USB3.0 Mono Camera (IMX249)

$499.00 $469.00

Available on backorder

SKU: Xena-M Category:

Player One Astronomy guiding camera series, AKA Dwarf Planet Series, is design for guiding and imaging. This series including 3 sub-series, Ceres, Sedna and Xena.



Product Description



Xena-M is a guiding camera developed by Player One Astronomy, which adopts the Sony IMX249 1/1.2” format sensor. The 5.86um pixel size accommodates a well depth of 32ke with a total of 2.3MP  (the resolution is 1936*1216), and the diagonal is 13.3mm.

This IMX249 sensor has same performance as IMX174 sensor, transmit speed of IMX249 is 48fps.

Highlights

Dwarf planet series integrated USB3.0 data port(500Mb/s), which can provide over 10 times speed than USB2.0 device(60Mb/s). Whatever you wants to do guiding or imaging, this camera series can handle it very well.

Dwarf planet camera diameter is 1.25″, it can slide in 1.25″ adapter of guiding scope, makes the whole setup shorter.



With a 5-100MM CS lens attached on the camera, it also can be used as a guider or finder.



Features:

The naming of Player One guiding cameras is interesting. Guiding camera is smaller than planetary camera, that’s why we choose dwarf planets to name it.

The size of each dwarf planet to a certain extent represents the size of camera sensors. We will name Ceres with a 1/3″ sensor camera, and for Xena, we will name it with a 1/1.2 inch sensor camera. All names will be engraved on the housing of the cameras.

Drivers and softwares download: http://player-one-astronomy.com/service/software/

Manuals download: http://player-one-astronomy.com/service/manuals/

Cutting-edge Design

The guiding cameras developed by Player One Astronomy uses technological regular hexagon to construct the main body line.

DPS technology

The guiding cameras from Player One Astronomy have DPS (Dead Pixel Suppression) technology, dead pixels (including both hot pixels and cold pixels) of the image are swept away. DPS function is turned on during your whole imaging session, no need to worry about it !

Overvoltage and overcurrent protection mechanism

Player One cameras produced by the number one player ensures the safety of your camera and other equipment through overvoltage and overcurrent protection mechanisms.

Data Port

When the camera is connected to the USB3.0 interface and full-resolution preview is used, it can reach 48 FPS in RAW8 mode (10bit ADC). When recording images, since the actual writing speed will be affected by the writing speed of the hard disk itself, when the hard disk writing speed is slow, the recording may not reach the theoretical speed. It is recommended that you use a high-quality solid state drive to record data to give full play to the performance of the camera.

Use the ST4 guide cable to connect the camera and the AUTO GUIDE port of the equatorial mount to do guiding.



Performance

graph is comming soon.

Readout Noise

Regarding readout noise, we solemnly promise that all values are obtained from actual tests.  And for users, you could use Sharpcap 4 for testing. SC4 has a function called Sensor Analysis, provide a very simple way to test readout noise.

We wrote a tutorial on our website: https://player-one-astronomy.com/service/manuals/

After many rigorous readout noise tests, the Xena-M camera can reach a low readout noise of 3.5e at a gain of 350.

If you are interested in readout noise testing, you may try it yourself, which is very simple.

QE Curve

Xena-M camera has about 77% QE peak.





Mechanical Drawing



Sensor

SONY IMX249 1/1.2" CMOS (mono)

Diagonal

13.3mm

Total Pixels

2.3 Mega Pixels

Max Resolution

1936×1216

Pixel Size

5.86μm

Chip Size

11.3×7.1mm

Frame Rate

30FPS(10bit)

Shutter

Global shutter

Exposure Range

32μs-2000s

Readout Noise

6.0e – 3.5e

QE Peak

≈77%

Full Well

32k e

ADC

12 bit

Data Port

USB3.0/USB2.0

Adapter

1.25″ / M28.5X0.6

Back Focal Length

7.5mm

Protective Window

AR coating

Diameter

40mm

Weight

65g

Resolution and FPS

Under USB3.0 mode
Resolution 10bit ADC
1936×1216 30 FPS
More resolution options could be setup in capture softewares!

Manual

Our product manual:

Manual

Download

Download drivers and softwares:

Software
